Continuing with the Clean Architecture Series, in this article we will create a specific structure to organize the CA layers and also packages to setup typescript.
So, let me walk through the process to setting up the project.
Create a folder project call "clean-architecture". Go inside the folder and run the following command to create a new project:
npm init --yes # this will trigger automatically populated initialization with default values
After that, we are going to create folders which represent the clean architecture layers:
src:
adapters: Interface adapters (controllers, gateways and presenters)
use-cases: Application business rules (use cases of the system)
domain: Enterprise business rules (Entities & Repositories)
frameworks: Frameworks, drivers and tools (Web framework, database, logger)
├── src
│ ├── adapters
│ ├── use-cases
│ ├── domain
│ └── frameworks
└── package.json
For setup typescript properly, we need to create the "tsconfig.json" file in the same level as "src" folder. We need to set a config similar to:
{
"compilerOptions": {
"module": "CommonJS",
"resolveJsonModule": true,
"esModuleInterop": true,
"allowSyntheticDefaultImports": true,
"target": "ES6",
"lib": [
"ES2019"
],
"moduleResolution": "node",
"sourceMap": true,
"outDir": "./dist",
"baseUrl": ".",
"paths": {
"@/adapters/*":[
"src/adapters/*"
],
"@/use-cases/*":[
"src/use-cases/*"
],
"@/domain/*":[
"src/domain/*"
],
"@/frameworks/*":[
"src/frameworks/*"
],
},
"types": ["node"],
"typeRoots": [
"node_modules/@types"
]
},
"include": [
"src/**/*.ts"
],
"exclude": [
"node_modules",
"dist"
]
}
Special mention for the path alias configuration property which allows us to have an one alias for each clean architecture layer: adapters, use-cases, domain and frameworks.
\If you are new to "TSConfig Path Aliases" itself, refer first to my previous article "[How to configure TSConfig Path Aliases](https://maxmartinez.dev/how-to-configure-tsconfig-path-aliases)" to setup properly the path aliases.*
And also express web server and the database package:
npm install express sqlite3
npm install -D @types/express @types/sqlite3
Finally, we will update the package.json file. Replace the scripts config with this:
...
"scripts": {
"build": "tsc --build && tsc-alias",
"start": "ts-node-dev --respawn -r tsconfig-paths/register ./src/frameworks/webserver/app.ts"
},
...
\With ts-node-dev we get the same experience as nodemon*.
\*Don't worry about the app.ts file, we will create it later.*
We are ready to coding our clean architecture project. See you in the next article.
